ABB R600 Series Solid State Relay, 12 A Load, DIN Rail Mount, 250 V Load, 24V dc Control
Technical Document
Specifications
Brand
ABBMaximum Load Current
12A
Product Type
Solid State Relay
Mount Type
DIN Rail
Maximum Load Voltage
250V
Minimum Load Voltage
5V
Minimum Control Voltage
5V ac/dc
Maximum Control Voltage
24V dc
Series
R600
Terminal Type
Screw
IP Rating
IP20
Minimum Operating Temperature
-20°C
Maximum Operating Temperature
70°C
Height
71mm
Length
73mm
Standards/Approvals
CEI 947-7-1, CEI 60664-1, CEI 1131-2, CEI 947-1, NEMA1, UL 94 V0, CEM:IRC 1000-4-2
Width
6mm
Output Type
Triac, Transistor, Relay, MOS
Off State Leakage Current
50μA
Product details
DIN Rail Mount Optocouplers R600 series
In order to fit voltage/current together with galvanic insulation, interface is necessary through devices providing these functions plus transmission of input/output logic signals.,The R600 range of relays and optocouplers makes it possible. These devices provide many voltage and current adjustments and input/output insulation.
Screw clamp Optocouplers
6mm large
Input voltage : From 5 to 250 Vac/dc
Voltage switching range : From 5 to 58 Vdc, From 20 to 400 Vac
Current switching range : From 1 mA to 5 A
Overvoltage protection
Stock information temporarily unavailable.
€ 65.31
€ 65.31 Each (ex VAT)
€ 77.72
€ 77.72 Each (inc. VAT)
1
€ 65.31
€ 65.31 Each (ex VAT)
€ 77.72
€ 77.72 Each (inc. VAT)
Stock information temporarily unavailable.
1
| quantity | Unit price |
|---|---|
| 1 - 4 | € 65.31 |
| 5 - 9 | € 63.01 |
| 10 - 24 | € 60.61 |
| 25 - 49 | € 58.11 |
| 50+ | € 55.44 |
