Omron PCB Mount Signal Relay, 24V dc Coil, 2A Switching Current, DPDT

RS Stock No.: 369-589Brand: OmronManufacturers Part No.: G6A-234P-ST-US DC24
brand-logo
View all in Signal Relays

Technical Document

Specifications

Brand

Omron

Coil Voltage

24V dc

Contact Configuration

DPDT

Mounting Type

PCB Mount

Series

Cradle N

Maximum Switching Power DC

70 W

Length

19mm

Depth

30mm

Height

35.5mm

Terminal Type

Through Hole

Number of Poles

4

Switching Current

2A

Application

Power

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+70°C

Maximum Switching Power AC

50VA

Coil Resistance

890Ω

Contact Material

Gold Plated

Country of Origin

Japan

Product details

G6A Series DPCO

Fully sealed
Low magnetic leakage
Impulse withstand voltage of 1500V
Ideal for telecommunications equipment

Approvals

UL, CSA

Ideate. Create. Collaborate

JOIN FOR FREE

No hidden fees!

design-spark
design-spark
  • Download and use our DesignSpark software for your PCB and 3D Mechanical designs
  • View and contribute website content and forums
  • Download 3D Models, Schematics and Footprints from more than a million products
Click here to find out more
Stock information temporarily unavailable.

€ 9.45

€ 9.45 Each (ex VAT)

€ 11.25

€ 11.25 Each (inc. VAT)

Omron PCB Mount Signal Relay, 24V dc Coil, 2A Switching Current, DPDT
Select packaging type

€ 9.45

€ 9.45 Each (ex VAT)

€ 11.25

€ 11.25 Each (inc. VAT)

Omron PCB Mount Signal Relay, 24V dc Coil, 2A Switching Current, DPDT
Stock information temporarily unavailable.
Select packaging type

Stock information temporarily unavailable.

Please check again later.

quantityUnit price
1 - 24€ 9.45
25 - 99€ 9.11
100 - 249€ 8.74
250 - 499€ 8.41
500+€ 8.04
