10kΩ, SMD Trimmer Potentiometer 0.25W Top Adjust Bourns, 3224
Technical Document
Specifications
Brand
BournsMaximum Resistance
10kΩ
Mounting Type
Surface Mount
Number of Turns
12
Orientation
Top Adjust
Power Rating
0.25W
Series
3224
Termination Style
J-Hook
Tolerance
±10%
Temperature Coefficient
±100ppm/°C
Length
4.8mm
Minimum Operating Temperature
-65°C
Maximum Operating Temperature
+150°C
Product details
12-Turn 250mW 4mm 3224W Series Top Adjust
Bourns Standard 3224W Series top adjust SMD Trimpot® trimming potentiometer with a power rating @ 70 °C of 0.25W. The 3224W series cermet trimmer features a flush adjustment screw, a pick and place centring design for automated placement compatibility and is Sealed to withstand standard board wash processing.
Miniature (nominal 4mm square case size)
Excellent mounting efficiency
Suitable for flow/reflow soldering/hand solder
Meets standard EIA and EIAJ footprint
Low CRV - 1%
Multi-Turn Surface Mount Trimmers
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
Please check again later.
€ 5.97
Each (In a Pack of 5) (ex VAT)
€ 7.104
Each (In a Pack of 5) (inc. VAT)
Standard
5
€ 5.97
Each (In a Pack of 5) (ex VAT)
€ 7.104
Each (In a Pack of 5) (inc. VAT)
Standard
5
Buy in bulk
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 20 | € 5.97 | € 29.85 |
| 25 - 45 | € 5.65 | € 28.25 |
| 50 - 95 | € 5.24 | € 26.20 |
| 100 - 245 | € 4.94 | € 24.70 |
| 250+ | € 4.39 | € 21.95 |
